Wall Mount Bracket
$10.50
Strap or bolt to pole or bolt to wall. Available in three sizes – 12-, 18- and 24-inch. Distance between the two 3/8-inch bolt holes on bracket from center-to-center are: 8-inch for the 12-inch bracket; 14-inch for the 18-inch bracket; and 20-inch for the 24-inch bracket. Bracket is 1-5/8 wide and is set off 13/16-inch from wall Suitable for both flat aluminum or extruded blanks. Bolt holes are 2 inches from top and bottom and 1/2-inch from side.
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Size |
12 Inch ,18 Inch ,24 Inch |
Key Features
Applications
Overview
Strap or bolt to pole or bolt to wall. Available in three sizes – 12-, 18- and 24-inch. Distance between the two 3/8-inch bolt holes on bracket from center-to-center are: 8-inch for the 12-inch bracket; 14-inch for the 18-inch bracket; and 20-inch for the 24-inch bracket. Bracket is 1-5/8 wide and is set off 13/16-inch from wall Suitable for both flat aluminum or extruded blanks. Bolt holes are 2 inches from top and bottom and 1/2-inch from side.
Specification
| Corners | Standard Federal Radius |
|---|---|
| Finish | Reflective |
| Hole Diameter | 3/8" |
| Hole Placement | Top and Bottom Centered |
| Hole Quantity | 2 |
| Legend | |
| Material | |
| MUTCD Identifier | |
| Shape | |
| Sheeting Color |
